Mammography acquisition parameters structure. More...
#include <mg_storage.h>
Public Attributes | |
| std::optional< double > | compression_force_n |
| Compression force in Newtons (0018,11A2) | |
| std::optional< double > | compressed_breast_thickness_mm |
| Compressed breast thickness in mm (0018,11A0) | |
| std::optional< double > | relative_x_ray_exposure |
| Relative X-ray exposure (0018,1405) | |
| std::optional< double > | entrance_dose_dgy |
| Entrance dose in dGy (0040,0302) | |
| std::optional< std::string > | entrance_dose_derivation |
| Entrance dose derivation (0040,0303) | |
| std::optional< double > | organ_dose_dgy |
| Organ dose in dGy (0040,0316) | |
| std::optional< double > | half_value_layer_mm |
| Half value layer in mm Al (0040,0314) | |
| std::optional< double > | kvp |
| KVP - X-ray tube peak kilovoltage (0018,0060) | |
| std::optional< double > | exposure_time_ms |
| Exposure time in ms (0018,1150) | |
| std::optional< double > | tube_current_ma |
| X-ray tube current in mA (0018,1151) | |
| std::optional< double > | exposure_mas |
| Exposure in mAs (0018,1153) | |
| std::optional< std::string > | anode_target_material |
| Anode target material (0018,1191) | |
| std::optional< std::string > | filter_material |
| Filter material (0018,7050) | |
| std::optional< double > | filter_thickness_mm |
| Filter thickness in mm (0018,7052) | |
| std::optional< double > | focal_spot_mm |
| Focal spot size in mm (0018,1190) | |
| std::optional< bool > | breast_implant_present |
| Breast implant present (0028,1300) | |
| std::optional< bool > | partial_view |
| Partial view flag (0028,1350) | |
| std::optional< std::string > | partial_view_description |
| Partial view description (0028,1351) | |
Detailed Description
Mammography acquisition parameters structure.
Contains key acquisition parameters specific to mammography imaging. These parameters are important for quality control and image interpretation.
Definition at line 211 of file mg_storage.h.
Member Data Documentation
◆ anode_target_material
| std::optional<std::string> kcenon::pacs::services::sop_classes::mg_acquisition_params::anode_target_material |
Anode target material (0018,1191)
Definition at line 246 of file mg_storage.h.
◆ breast_implant_present
| std::optional<bool> kcenon::pacs::services::sop_classes::mg_acquisition_params::breast_implant_present |
Breast implant present (0028,1300)
Definition at line 258 of file mg_storage.h.
◆ compressed_breast_thickness_mm
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::compressed_breast_thickness_mm |
Compressed breast thickness in mm (0018,11A0)
Definition at line 216 of file mg_storage.h.
◆ compression_force_n
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::compression_force_n |
Compression force in Newtons (0018,11A2)
Definition at line 213 of file mg_storage.h.
◆ entrance_dose_derivation
| std::optional<std::string> kcenon::pacs::services::sop_classes::mg_acquisition_params::entrance_dose_derivation |
Entrance dose derivation (0040,0303)
Definition at line 225 of file mg_storage.h.
◆ entrance_dose_dgy
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::entrance_dose_dgy |
Entrance dose in dGy (0040,0302)
Definition at line 222 of file mg_storage.h.
◆ exposure_mas
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::exposure_mas |
Exposure in mAs (0018,1153)
Definition at line 243 of file mg_storage.h.
◆ exposure_time_ms
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::exposure_time_ms |
Exposure time in ms (0018,1150)
Definition at line 237 of file mg_storage.h.
◆ filter_material
| std::optional<std::string> kcenon::pacs::services::sop_classes::mg_acquisition_params::filter_material |
Filter material (0018,7050)
Definition at line 249 of file mg_storage.h.
◆ filter_thickness_mm
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::filter_thickness_mm |
Filter thickness in mm (0018,7052)
Definition at line 252 of file mg_storage.h.
◆ focal_spot_mm
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::focal_spot_mm |
Focal spot size in mm (0018,1190)
Definition at line 255 of file mg_storage.h.
◆ half_value_layer_mm
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::half_value_layer_mm |
Half value layer in mm Al (0040,0314)
Definition at line 231 of file mg_storage.h.
◆ kvp
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::kvp |
KVP - X-ray tube peak kilovoltage (0018,0060)
Definition at line 234 of file mg_storage.h.
◆ organ_dose_dgy
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::organ_dose_dgy |
Organ dose in dGy (0040,0316)
Definition at line 228 of file mg_storage.h.
◆ partial_view
| std::optional<bool> kcenon::pacs::services::sop_classes::mg_acquisition_params::partial_view |
Partial view flag (0028,1350)
Definition at line 261 of file mg_storage.h.
◆ partial_view_description
| std::optional<std::string> kcenon::pacs::services::sop_classes::mg_acquisition_params::partial_view_description |
Partial view description (0028,1351)
Definition at line 264 of file mg_storage.h.
◆ relative_x_ray_exposure
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::relative_x_ray_exposure |
Relative X-ray exposure (0018,1405)
Definition at line 219 of file mg_storage.h.
◆ tube_current_ma
| std::optional<double> kcenon::pacs::services::sop_classes::mg_acquisition_params::tube_current_ma |
X-ray tube current in mA (0018,1151)
Definition at line 240 of file mg_storage.h.
The documentation for this struct was generated from the following file:
- include/kcenon/pacs/services/sop_classes/mg_storage.h
