kcenon::network::protocols::grpc::grpc_client Class Reference

gRPC client for making RPC calls More...

#include <client.h>

Collaboration diagram for kcenon::network::protocols::grpc::grpc_client:

Classes
class	bidi_stream
	Bidirectional streaming RPC handle. More...
class	client_stream_writer
	Writer for client streaming RPC. More...
class	impl
class	server_stream_reader
	Reader for server streaming RPC. More...

Public Member Functions
	grpc_client (const std::string &target, const grpc_channel_config &config={})
	Construct gRPC client.
	~grpc_client ()
	Destructor.
	grpc_client (const grpc_client &)=delete
grpc_client &	operator= (const grpc_client &)=delete
	grpc_client (grpc_client &&) noexcept
grpc_client &	operator= (grpc_client &&) noexcept
auto	connect () -> VoidResult
	Connect to the server.
auto	disconnect () -> void
	Disconnect from the server.
auto	is_connected () const -> bool
	Check if connected.
auto	wait_for_connected (std::chrono::milliseconds timeout) -> bool
	Wait for connection to be ready.
auto	target () const -> const std::string &
	Get the target address.
auto	call_raw (const std::string &method, const std::vector< uint8_t > &request, const call_options &options={}) -> Result< grpc_message >
	Make a unary RPC call.
auto	call_raw_async (const std::string &method, const std::vector< uint8_t > &request, std::function< void(Result< grpc_message >)> callback, const call_options &options={}) -> void
	Make an async unary RPC call.
auto	server_stream_raw (const std::string &method, const std::vector< uint8_t > &request, const call_options &options={}) -> Result< std::unique_ptr< server_stream_reader > >
	Start a server streaming RPC call.
auto	client_stream_raw (const std::string &method, const call_options &options={}) -> Result< std::unique_ptr< client_stream_writer > >
	Start a client streaming RPC call.
auto	bidi_stream_raw (const std::string &method, const call_options &options={}) -> Result< std::unique_ptr< bidi_stream > >
	Start a bidirectional streaming RPC call.

Private Attributes
std::unique_ptr< impl >	impl_

Detailed Description

gRPC client for making RPC calls

This class provides a client interface for making gRPC calls over HTTP/2 transport. It supports unary and streaming RPC calls.

Note

This is a prototype implementation. For production use, consider wrapping the official gRPC library.

Definition at line 114 of file client.h.

Constructor & Destructor Documentation

grpc_client() [1/3]

kcenon::network::protocols::grpc::grpc_client::grpc_client ( const std::string & target, const grpc_channel_config & config = {} )

explicit

Construct gRPC client.

Parameters

target	Target address (e.g., "localhost:50051")
config	Channel configuration

Definition at line 1629 of file client.cpp.

    : impl_(std::make_unique<impl>(target, config))
{
}

References config.

~grpc_client()

kcenon::network::protocols::grpc::grpc_client::~grpc_client ( )

default

Destructor.

grpc_client() [2/3]

kcenon::network::protocols::grpc::grpc_client::grpc_client ( const grpc_client & )

delete

grpc_client() [3/3]

kcenon::network::protocols::grpc::grpc_client::grpc_client ( grpc_client && )

defaultnoexcept

Member Function Documentation

bidi_stream_raw()

auto kcenon::network::protocols::grpc::grpc_client::bidi_stream_raw	(	const std::string &	method,
		const call_options &	options = {} ) -> Result<std::unique_ptr<bidi_stream>>

Start a bidirectional streaming RPC call.

Parameters

method	Full method name
options	Call options

Returns

Bidirectional stream handle or error

Definition at line 1695 of file client.cpp.

{
    return impl_->bidi_stream_raw(method, options);
}

call_raw()

auto kcenon::network::protocols::grpc::grpc_client::call_raw	(	const std::string &	method,
		const std::vector< uint8_t > &	request,
		const call_options &	options = {} ) -> Result<grpc_message>

Make a unary RPC call.

Parameters

method	Full method name (e.g., "/package.Service/Method")
request	Serialized request message
options	Call options

Returns

Result containing serialized response or error status

Example:

auto result = client.call_raw("/helloworld.Greeter/SayHello",
                              serialize(request));
if (result.is_ok()) {
    auto response = deserialize<HelloReply>(result.value().data);
}

Definition at line 1665 of file client.cpp.

{
    return impl_->call_raw(method, request, options);
}

call_raw_async()

auto kcenon::network::protocols::grpc::grpc_client::call_raw_async	(	const std::string &	method,
		const std::vector< uint8_t > &	request,
		std::function< void(Result< grpc_message >)>	callback,
		const call_options &	options = {} ) -> void

Make an async unary RPC call.

Parameters

method	Full method name
request	Serialized request message
callback	Callback with result
options	Call options

Definition at line 1672 of file client.cpp.

{
    impl_->call_raw_async(method, request, std::move(callback), options);
}

client_stream_raw()

auto kcenon::network::protocols::grpc::grpc_client::client_stream_raw	(	const std::string &	method,
		const call_options &	options = {} ) -> Result<std::unique_ptr<client_stream_writer>>

Start a client streaming RPC call.

Parameters

method	Full method name
options	Call options

Returns

Stream writer or error

Definition at line 1688 of file client.cpp.

{
    return impl_->client_stream_raw(method, options);
}

connect()

auto kcenon::network::protocols::grpc::grpc_client::connect

(

)

-> VoidResult

Connect to the server.

Returns

Success or error

Definition at line 1640 of file client.cpp.

{
    return impl_->connect();
}

disconnect()

auto kcenon::network::protocols::grpc::grpc_client::disconnect

(

)

-> void

Disconnect from the server.

Definition at line 1645 of file client.cpp.

{
    impl_->disconnect();
}

is_connected()

auto kcenon::network::protocols::grpc::grpc_client::is_connected

(

)

const -> bool

Check if connected.

Returns

True if connected

Definition at line 1650 of file client.cpp.

{
    return impl_->is_connected();
}

References impl_, and kcenon::network::protocols::grpc::grpc_client::impl::is_connected().

Here is the call graph for this function:

operator=() [1/2]

grpc_client & kcenon::network::protocols::grpc::grpc_client::operator= ( const grpc_client & )

delete

operator=() [2/2]

grpc_client & kcenon::network::protocols::grpc::grpc_client::operator= ( grpc_client && )

defaultnoexcept

server_stream_raw()

auto kcenon::network::protocols::grpc::grpc_client::server_stream_raw	(	const std::string &	method,
		const std::vector< uint8_t > &	request,
		const call_options &	options = {} ) -> Result<std::unique_ptr<server_stream_reader>>

Start a server streaming RPC call.

Parameters

method	Full method name
request	Serialized request message
options	Call options

Returns

Stream reader or error

Definition at line 1680 of file client.cpp.

{
    return impl_->server_stream_raw(method, request, options);
}

target()

auto kcenon::network::protocols::grpc::grpc_client::target

(

)

const -> const std::string&

Get the target address.

Returns

Target address string

Definition at line 1660 of file client.cpp.

{
    return impl_->target();
}

References impl_, and kcenon::network::protocols::grpc::grpc_client::impl::target().

Here is the call graph for this function:

wait_for_connected()

auto kcenon::network::protocols::grpc::grpc_client::wait_for_connected

(

std::chrono::milliseconds

timeout

)

-> bool

Wait for connection to be ready.

Parameters

timeout

Maximum time to wait

Returns

True if connected within timeout

Definition at line 1655 of file client.cpp.

{
    return impl_->wait_for_connected(timeout);
}

Member Data Documentation

impl_

std::unique_ptr<impl> kcenon::network::protocols::grpc::grpc_client::impl_

private

Definition at line 326 of file client.h.

Referenced by is_connected(), and target().

---

The documentation for this class was generated from the following files:

• include/kcenon/network/detail/protocols/grpc/client.h
• src/protocols/grpc/client.cpp
