status_codes.h File Reference

DIMSE status codes. More...

#include <cstdint>
#include <string_view>

Include dependency graph for status_codes.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
namespace	kcenon
namespace	kcenon::pacs
namespace	kcenon::pacs::network
namespace	kcenon::pacs::network::dimse

Typedefs
using	kcenon::pacs::network::dimse::status_code = uint16_t
	DIMSE status code type alias.

Functions
Status Type Categories
constexpr bool	kcenon::pacs::network::dimse::is_success (status_code status) noexcept
	Check if status indicates success.
constexpr bool	kcenon::pacs::network::dimse::is_pending (status_code status) noexcept
	Check if status indicates pending (more results)
constexpr bool	kcenon::pacs::network::dimse::is_cancel (status_code status) noexcept
	Check if status indicates cancellation.
constexpr bool	kcenon::pacs::network::dimse::is_warning (status_code status) noexcept
	Check if status indicates a warning.
constexpr bool	kcenon::pacs::network::dimse::is_failure (status_code status) noexcept
	Check if status indicates a failure.
constexpr bool	kcenon::pacs::network::dimse::is_final (status_code status) noexcept
	Check if this is a final status (operation complete)
Status Code String Conversion
constexpr std::string_view	kcenon::pacs::network::dimse::status_description (status_code status) noexcept
	Get a human-readable description of a status code.
constexpr std::string_view	kcenon::pacs::network::dimse::status_category (status_code status) noexcept
	Get the category name for a status code.

Variables
General Status Codes
constexpr status_code	kcenon::pacs::network::dimse::status_success = 0x0000
	Operation completed successfully.
constexpr status_code	kcenon::pacs::network::dimse::status_pending = 0xFF00
	Operation pending (more results available)
constexpr status_code	kcenon::pacs::network::dimse::status_pending_warning = 0xFF01
	Pending with optional keys not supported.
constexpr status_code	kcenon::pacs::network::dimse::status_cancel = 0xFE00
	Operation was canceled.
Failure Status Codes (0xCxxx, 0xAxxx)
constexpr status_code	kcenon::pacs::network::dimse::status_refused_out_of_resources = 0xA700
	Refused: Out of resources.
constexpr status_code	kcenon::pacs::network::dimse::status_refused_out_of_resources_matches = 0xA701
	Refused: Out of resources - Unable to calculate number of matches.
constexpr status_code	kcenon::pacs::network::dimse::status_refused_out_of_resources_subops = 0xA702
	Refused: Out of resources - Unable to perform sub-operations.
constexpr status_code	kcenon::pacs::network::dimse::status_refused_move_destination_unknown = 0xA801
	Refused: Move destination unknown.
constexpr status_code	kcenon::pacs::network::dimse::status_refused_sop_class_not_supported = 0x0122
	Refused: SOP class not supported.
constexpr status_code	kcenon::pacs::network::dimse::status_error_dataset_mismatch = 0xA900
	Error: Data set does not match SOP class.
constexpr status_code	kcenon::pacs::network::dimse::status_error_cannot_understand = 0xC000
	Error: Cannot understand.
constexpr status_code	kcenon::pacs::network::dimse::status_error_unable_to_process = 0xC001
	Error: Unable to process.
constexpr status_code	kcenon::pacs::network::dimse::status_error_duplicate_sop_instance = 0x0111
	Error: Duplicate SOP instance.
constexpr status_code	kcenon::pacs::network::dimse::status_error_missing_attribute = 0x0120
	Error: Missing attribute.
constexpr status_code	kcenon::pacs::network::dimse::status_error_missing_attribute_value = 0x0121
	Error: Missing attribute value.
DIMSE-N Specific Failure Status Codes
constexpr status_code	kcenon::pacs::network::dimse::status_error_attribute_list_error = 0x0107
	Error: Attribute list error (N-CREATE)
constexpr status_code	kcenon::pacs::network::dimse::status_error_attribute_value_out_of_range = 0x0116
	Error: Attribute value out of range (N-SET)
constexpr status_code	kcenon::pacs::network::dimse::status_error_invalid_object_instance = 0x0117
	Error: Invalid object instance (N-SET, N-GET, N-ACTION, N-DELETE)
constexpr status_code	kcenon::pacs::network::dimse::status_error_no_such_sop_class = 0x0118
	Error: No such SOP class (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_class_instance_conflict = 0x0119
	Error: Class-instance conflict (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_not_authorized = 0x0124
	Error: Not authorized (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_duplicate_invocation = 0x0210
	Error: Duplicate invocation (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_unrecognized_operation = 0x0211
	Error: Unrecognized operation (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_mistyped_argument = 0x0212
	Error: Mistyped argument (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_resource_limitation = 0x0213
	Error: Resource limitation (All DIMSE-N)
constexpr status_code	kcenon::pacs::network::dimse::status_error_no_such_action_type = 0x0123
	Error: No such action type (N-ACTION)
constexpr status_code	kcenon::pacs::network::dimse::status_error_no_such_event_type = 0x0113
	Error: No such event type (N-EVENT-REPORT)
constexpr status_code	kcenon::pacs::network::dimse::status_error_processing_failure = 0x0110
	Error: Processing failure (All DIMSE-N)
Warning Status Codes (0xBxxx)
constexpr status_code	kcenon::pacs::network::dimse::status_warning_coercion = 0xB000
	Warning: Coercion of data elements.
constexpr status_code	kcenon::pacs::network::dimse::status_warning_dataset_mismatch = 0xB007
	Warning: Data set does not match SOP class (non-fatal)
constexpr status_code	kcenon::pacs::network::dimse::status_warning_elements_discarded = 0xB006
	Warning: Elements discarded.
constexpr status_code	kcenon::pacs::network::dimse::status_warning_subops_complete_failures = 0xB000
	Warning: Sub-operations complete with failures.

Detailed Description

DIMSE status codes.

This file defines the DIMSE status codes as specified in DICOM PS3.7. Status codes are returned in response messages to indicate the result of a DIMSE operation.

See also

DICOM PS3.7 Annex C - Status Type Encoding

Author

kcenon

Since

1.0.0

Definition in file status_codes.h.
