n_set.h File Reference

N-SET DIMSE service. More...

#include "dimse_message.h"

Include dependency graph for n_set.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
namespace	kcenon
namespace	kcenon::pacs
namespace	kcenon::pacs::network
namespace	kcenon::pacs::network::dimse

Detailed Description

N-SET DIMSE service.

N-SET is used to modify attributes of a managed SOP Instance. It is primarily used for normalized SOP Classes such as MPPS to update procedure step status.

See also

DICOM PS3.7 Section 10.1.3 - N-SET Service

Usage Example

// SCU updates MPPS status to COMPLETED
auto rq = make_n_set_rq(2, mpps_sop_class_uid, instance_uid);
core::dicom_dataset modification;
modification.set_string(tags::performed_procedure_step_status, vr_type::CS, "COMPLETED");
rq.set_dataset(std::move(modification));

// SCP responds
auto rsp = make_n_set_rsp(2, mpps_sop_class_uid, instance_uid, status_success);

Command Elements

Tag	Keyword	Request	Response
(0000,0003)	RequestedSOPClassUID	M	-
(0000,0002)	AffectedSOPClassUID	-	M
(0000,0100)	CommandField	M (0x0120/0x8120)	M
(0000,0110)	MessageID	M	-
(0000,0120)	MessageIDBeingRespondedTo	-	M
(0000,0800)	CommandDataSetType	M	M
(0000,0900)	Status	-	M
(0000,1001)	RequestedSOPInstanceUID	M	-
(0000,1000)	AffectedSOPInstanceUID	-	M

M = Mandatory

Author

kcenon

Since

1.0.0

Definition in file n_set.h.
